Prestressed Concrete 7 Wire PC Strand Width 0.76m For Bridge Construction

Prestressed Concrete 7 Wire PC Strand Width 0.76m For Bridge Construction

    • Prestressed Concrete 7 Wire PC Strand Width 0.76m For Bridge Construction
    • Prestressed Concrete 7 Wire PC Strand Width 0.76m For Bridge Construction
    • Prestressed Concrete 7 Wire PC Strand Width 0.76m For Bridge Construction
  • Prestressed Concrete 7 Wire PC Strand Width 0.76m For Bridge Construction

    পণ্যের বিবরণ:

    Place of Origin: Anhui,China
    পরিচিতিমুলক নাম: Litong Global
    সাক্ষ্যদান: ISO9001-2008
    Model Number: LT-1612051

    প্রদান:

    Minimum Order Quantity: Negotiable
    মূল্য: Negotiable
    Packaging Details: Standard export seaworthy packing in coil on 2 pallets
    Supply Ability: 1000tons/day
    যোগাযোগ
    বিস্তারিত পণ্যের বর্ণনা
    Material: 82B with 11mm and 13mm PC Strand size: 12.7mm and 15.24mm
    Application: Construction Wire Mesh Metal Wire Drawing: Hot Drawing
    Structure: 1*7 Steel Wires Tensil Strength: 1860-2100MPA
    Coil weight: 2.0-3.2tons Relaxation at 1000h Not More Than: 2.5%
    Alloy or Not: Non-Alloy Specification: Astma416, Bs5896, En10138-3, as/Nzs4672, GB/T5224
    Coil Size: ID 0.70-0.72m, Od 1.0-1.5m, Width 0.76m
    লক্ষণীয় করা:

    seven strand wire

    ,

    7 wire PC Strand

    7 wire PC Strand for bridge



    1. Other Diameters are available as per customers' request.
    2. Standard: ASTMA416, BS5896, EN10138-3, AS/NZS4672, GB/T5224, KS7002, ISO6934-4, JISG3536.
    3. Application: Construction material, widely used
    4. Packing and weight: Coil at customer's requirement. (water-proof packing with wood pallets)
    5. Minimum order: 25tons
    6. Payment term: T/T or L/C





    7-Wire Uncoated Steel Strand for Prestressed Concrete as per ASTM A 416

    Min.Breaking Strength

    Nominal

    Dia.

    Dia.

    Tolerance

    Norminal

    Steel

    Area

    Nominal Weight

    Min.

    Breaking Load

    Min.Load

    at 1%Extension

    Min.Elongation

    Lo≥610mm

    0.7 G.U.T.S

    1000hNorminal Relaxation

    MPA mm mm Mm2 Kg/Km KN KN % %
    1860 9.53





    +0.66,-0.15

    54.84 432 102.3 92.1





    ≥3.5





    ≤2.5

    11.11 74.19 582 137.9 124.1
    12.70 98.7 775 183.7 165.3
    15.24 140.0 1102 260.7 234.6
    17.80 190.0 1492 353.0 318.0
    2000 12.70 +0.66,-0.15 98.7 775 197.4 177.7 ≥3.5 ≤2.5
    15.24 140.0 1102 280.0 252.0



    Welcome to enquiry our PC Strand



    Nancy



    nancylsl AT hotmail.com



    What'app:0086-13855514957





    Prestressed Concrete 7 Wire PC Strand Width 0.76m For Bridge Construction 0

    Prestressed Concrete 7 Wire PC Strand Width 0.76m For Bridge Construction 1

    Prestressed Concrete 7 Wire PC Strand Width 0.76m For Bridge Construction 2
